Product parameters
Model: YIDIMU 10.1Inch
Technology: Photocuring
Level: Desktop
Molding material: Photosensitive resin
Machine power: 115W
Molding size: 223×126×290mm
Maximum printing speed: 6cm/h
Warranty of the whole machine: 1 year
Resolution: 13320×5120 black and white screen
Screen size: 10.1 inches
Molding light source: 405nmUVA parallel light source
Printing layer thickness: 0.02-0.1
XY axis accuracy: 0.05mm
Z axis type: ball screw
Touch screen: 5.0 inches
Optimum molding temperature: 30-40°
Power input: AC100-240V/50-60HZ
System requirements: Windows7 (64-bit) and above, 4GBRAM
Connection requirements: USB Ethernet
Original file format: STL\OBJ
Print file format: .ctb format
UV curing wavelength: 405nm
Slicing software: CHITUBOX
Print support: Support can be automatically generated
Product size: 350 (L) × 385 (W) × 665 (H) mm
Net weight: 500 (L) × 500 (W) × 740 (H) mm
Outer packaging size: 500 (L) × 500 (W) × 740 (H) mm
Gross weight: 34kg carton
Material trough: Material AL6061
Mainboard: M20 motherboard
Motor: Closed-loop motor driver board + 57 motor
Internal power supply: Multi-function integrated power supply
